今天总结下SpringBoot 封装组件的几种方式,第一种:基于application.properties 配置文件+spring 注解标签方式,实现相关组件的封装:

任务要求:常用SQL 脚本方式完成定时任务的建表、查询、新增、修改和删除的功能操作,同时封装为组件,方便其他业务模块的调用。

核心代码如下:

第一:功能组件的相关配置参数:

import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Component;

@Component
public class CronTaskConfigEntity {
	// cron 数据库url 地址
	@Value("${com.ucas.cron.database.url}")
	private String url;
	// cron 数据库用户名称
	@Value("${com.ucas.cron.database.username}")
	private String username;
	// cron 数据库密码
	@Value("${com.ucas.cron.database.password}")
	private String password;
	// cron 数据库驱动
	@Value("${com.ucas.cron.database.driverClassName}")
	private String driverClassName;
	// set 和   get 方法
	public String getUrl() {
		return url;
	}
	public void setUrl(String url) {
		this.url = url;
	}
	public String getUsername() {
		return username;
	}
	public void setUsername(String username) {
		this.username = username;
	}
	public String getPassword() {
		return password;
	}
	public void setPassword(String password) {
		this.password = password;
	}
	public String getDriverClassName() {
		return driverClassName;
	}
	public void setDriverClassName(String driverClassName) {
		this.driverClassName = driverClassName;
	}


}

第二:实列化对象:

import java.io.Serializable;
import java.util.Date;

@SuppressWarnings("serial")
public class CronTask implements Serializable{

	private Long id;

	private String task_name;

	private String cron;

	private String class_name;

	private String method_name;

	private Integer type_;

	private Integer state_;

	private String remark_;

	private String created_by;

	private Date created_dt;

	// set 和   get 方法

	public Long getId() {
		return id;
	}

	public void setId(Long id) {
		this.id = id;
	}

	public String getTask_name() {
		return task_name;
	}

	public void setTask_name(String task_name) {
		this.task_name = task_name;
	}

	public String getCron() {
		return cron;
	}

	public void setCron(String cron) {
		this.cron = cron;
	}

	public String getClass_name() {
		return class_name;
	}

	public void setClass_name(String class_name) {
		this.class_name = class_name;
	}

	public String getMethod_name() {
		return method_name;
	}

	public void setMethod_name(String method_name) {
		this.method_name = method_name;
	}

	public Integer getType_() {
		return type_;
	}

	public void setType_(Integer type_) {
		this.type_ = type_;
	}

	public Integer getState_() {
		return state_;
	}

	public void setState_(Integer state_) {
		this.state_ = state_;
	}

	public String getRemark_() {
		return remark_;
	}

	public void setRemark_(String remark_) {
		this.remark_ = remark_;
	}

	public String getCreated_by() {
		return created_by;
	}

	public void setCreated_by(String created_by) {
		this.created_by = created_by;
	}

	public Date getCreated_dt() {
		return created_dt;
	}

	public void setCreated_dt(Date created_dt) {
		this.created_dt = created_dt;
	}
}

三、查询字段与实体对象转换。

import java.sql.ResultSet;
import java.sql.SQLException;
import org.springframework.jdbc.core.RowMapper;
import com.ucas.cron.domain.CronTask;

public class CronTaskMapper implements RowMapper<CronTask> {

	@Override
	public CronTask mapRow(ResultSet rs, int rowNum) throws SQLException {
		// TODO Auto-generated method stub
		CronTask object = new CronTask();
		object.setId(rs.getLong("id"));
		object.setClass_name(rs.getString("class_name"));
		object.setCron(rs.getString("cron"));
		object.setMethod_name(rs.getString("method_name"));
		object.setRemark_(rs.getString("remark_"));
		object.setState_(rs.getInt("state_"));
		object.setTask_name(rs.getString("task_name"));
		object.setType_(rs.getInt("type_"));
		return object;
	}

}

四、定时任务工具类:基于springboot jdbc

import java.sql.Connection;
import java.sql.DatabaseMetaData;
import java.sql.ResultSet;
import java.sql.SQLException;
import java.util.List;
import org.springframework.jdbc.core.JdbcTemplate;
import com.ucas.cron.domain.CronTask;
import com.ucas.cron.mapper.CronTaskMapper;

/**
 * cron 工具类封装
 *
 * @author zzg
 *
 */
public class CronTaskUtil {
	private JdbcTemplate template;

	// set 和 get 方法
	public JdbcTemplate getTemplate() {
		return template;
	}

	public void setTemplate(JdbcTemplate template) {
		this.template = template;
	}

	// 表sql是否存在
	String tableName = "sys_cron";
	// 建表sql
	String create = "create table sys_cron (" + " id bigint(15) not null comment '主键',"
			+ " task_name varchar(128) comment '任务名称'," + " cron varchar(64) comment '时间规则',"
			+ " class_name varchar(64) comment '类名'," + " method_name varchar(64) comment '方法名称',"
			+ " type_ tinyint(4) comment '任务类型:1:系统初始化 2:自定义'," + " state_ tinyint(4) comment '状态: 1:启用,2:禁用',"
			+ " remark_ varchar(64) comment '备注'," + " created_by varchar(64) comment '创建人',"
			+ " created_dt datetime comment '创建时间'," + " primary key (id)" + " )";
	// 新增sql
	String insert = "insert into sys_cron(id, task_name, cron, class_name, method_name, type_, state_, remark_) values (?,?,?,?,?,?,?,?)";

	// 删除sql
	String delete = "delete from sys_cron where id = ?";

	// 更新sql
	String update = "update sys_cron set state_ = ? where id = ?";

	// 查询sql
	String select = "select id, task_name, cron, class_name, method_name, type_, state_, remark_ from sys_cron";

	/**
	 * sys_cron 初始化方法
	 *
	 * @return
	 * @throws SQLException
	 */
	public boolean init() throws SQLException {

		Connection conn = template.getDataSource().getConnection();
		ResultSet tabs = null;
		try {
			DatabaseMetaData dbMetaData = conn.getMetaData();
			String[] types = { "TABLE" };
			tabs = dbMetaData.getTables(null, null, tableName, types);
			if (tabs.next()) {
				return true;
			}
		} catch (Exception e) {
			e.printStackTrace();
		} finally {
			tabs.close();
			conn.close();
		}
		return false;
	}

	/**
	 * sys_cron 插入
	 *
	 * @param entity
	 * @throws SQLException
	 */
	public void insert(CronTask entity) throws SQLException {
		if (!init()) {
			template.execute(create);
		}
		template.update(insert, entity.getId(), entity.getTask_name(), entity.getCron(), entity.getClass_name(),
				entity.getMethod_name(), entity.getType_(), entity.getState_(), entity.getRemark_());
	}

	/**
	 * sys_cron 删除
	 *
	 * @param entity
	 */
	public void delete(String id) {
		template.update(delete, id);
	}

	/**
	 * sys_cron 更新
	 */

	public void update(Integer state, Long id) {
		template.update(update, state, id);
	}

	/**
	 * sys_cron 查询
	 *
	 * @throws SQLException
	 */
	public List<CronTask> select() throws SQLException {
		if (!init()) {
			template.execute(create);
		}

		List<CronTask> list = template.query(select, new CronTaskMapper());
		return list;
	}
}

五、springboot 配置对象,实现化自定义工具类对象:

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.jdbc.core.JdbcTemplate;
import org.springframework.jdbc.datasource.DriverManagerDataSource;

import com.ucas.cron.config.domain.CronTaskConfigEntity;
import com.ucas.cron.util.CronTaskUtil;

@Configuration
public class CronTaskConfig {

	@Autowired
	private CronTaskConfigEntity config;

	/**
	 * DataSource
	 * @return
	 */
	public DriverManagerDataSource getDataSources(){
		DriverManagerDataSource dataSource = new DriverManagerDataSource();
		dataSource.setDriverClassName(config.getDriverClassName());
		dataSource.setUrl(config.getUrl());
		dataSource.setUsername(config.getUsername());
		dataSource.setPassword(config.getPassword());
		return dataSource;
	}

	/**
	 * JdbcTemplate
	 * @return
	 */
	public JdbcTemplate getJdbcTemplates(){
		JdbcTemplate template = new JdbcTemplate(getDataSources());
		return template;
	}
	/**
	 * CronTaskUtil
	 * @return
	 */
	@Bean(name = "cronTaskUtil")
	public CronTaskUtil getCronTaskUtil(){
		CronTaskUtil util = new CronTaskUtil();
		util.setTemplate(getJdbcTemplates());
		return util;
	}

}

自此,组件的相关功能编码已经全部完成。

将改组件模块打包成jar 包,方便业务模块的调用。

通用war 设计图:

公共依赖的pom.xml 文件:

<!-- 集中定义管理依赖版本号 -->
	<properties>
		<spring.version>4.3.21.RELEASE</spring.version>
		<commons-lang.version>2.6</commons-lang.version>
		<commons-codec.version>1.10</commons-codec.version>
		<commons-lang3.version>3.8.1</commons-lang3.version>
		<commons-net.version>3.6</commons-net.version>
		<commons-io.version>2.6</commons-io.version>
		<commons-collections.version>3.2.1</commons-collections.version>
		<servlet-api.version>3.1.0</servlet-api.version>
		<fastjson.version>1.2.48</fastjson.version>
		<oshi-core.version>3.9.1</oshi-core.version>
		<mysql-connector-java.version>8.0.11</mysql-connector-java.version>
		<spring-data-redis.version>2.1.2.RELEASE</spring-data-redis.version>
		<jedis.version>3.0.1</jedis.version>
	</properties>

	<!--digipower core 核心jar 包依赖 -->
	<dependencies>
		<!--spring IOC 功能 -->
		<!--spring-core 核心包 -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-core</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<!--spring-context 全局IOC容器 -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-context</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<!--spring-context-support 拓展 -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-context-support</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<!--spring-beans Bean注册 -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-beans</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<!--spring-experession EL表达式 -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-expression</artifactId>
			<version>${spring.version}</version>
		</dependency>

		<!-- Spring AOP 功能 -->
		<!-- 集成spring-aop -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-aop</artifactId>
			<version>${spring.version}</version>
		</dependency>

		<!-- Spring JDBC 功能 -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-jdbc</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-tx</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<!--spring web功能  -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-web</artifactId>
			<version>${spring.version}</version>
		</dependency>
		<!-- mysql 数据库驱动jar -->
		<dependency>
			<groupId>mysql</groupId>
			<artifactId>mysql-connector-java</artifactId>
			<version>${mysql-connector-java.version}</version>
		</dependency>

		<!--集成AspectJ -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-aspects</artifactId>
			<version>${spring.version}</version>
		</dependency>

		<!--common-lang 常用工具包 -->
		<dependency>
			<groupId>commons-lang</groupId>
			<artifactId>commons-lang</artifactId>
			<version>${commons-lang.version}</version>
		</dependency>
		<!--commons-lang3 工具包 -->
		<dependency>
			<groupId>org.apache.commons</groupId>
			<artifactId>commons-lang3</artifactId>
			<version>${commons-lang3.version}</version>
		</dependency>

		<!--commons-codec 加密工具包 -->
		<dependency>
			<groupId>commons-codec</groupId>
			<artifactId>commons-codec</artifactId>
			<version>${commons-codec.version}</version>
		</dependency>
		<!--commons-net 网络工具包 -->
		<dependency>
			<groupId>commons-net</groupId>
			<artifactId>commons-net</artifactId>
			<version>${commons-net.version}</version>
		</dependency>
		<!--common-io 工具包 -->
		<dependency>
			<groupId>commons-io</groupId>
			<artifactId>commons-io</artifactId>
			<version>${commons-io.version}</version>
		</dependency>
		<!--common-collection 工具包 -->
		<dependency>
			<groupId>commons-collections</groupId>
			<artifactId>commons-collections</artifactId>
			<version>${commons-collections.version}</version>
		</dependency>

		<!-- 集成servlet -->
		<dependency>
			<groupId>javax.servlet</groupId>
			<artifactId>javax.servlet-api</artifactId>
			<version>${servlet-api.version}</version>
		</dependency>
		<!-- fastjson -->
		<dependency>
			<groupId>com.alibaba</groupId>
			<artifactId>fastjson</artifactId>
			<version>${fastjson.version}</version>
		</dependency>

		<!--windows 系统性能监控依赖jar -->
		<dependency>
			<groupId>com.github.oshi</groupId>
			<artifactId>oshi-core</artifactId>
			<version>${oshi-core.version}</version>
		</dependency>
		<!-- redis 功能模块集成  -->
		<!-- redis-spring适配器 -->
		<dependency>
			<groupId>org.springframework.data</groupId>
			<artifactId>spring-data-redis</artifactId>
			<version>${spring-data-redis.version}</version>
		</dependency>
		<!--redis客户端 依赖 -->
		<dependency>
			<groupId>redis.clients</groupId>
			<artifactId>jedis</artifactId>
			<version>${jedis.version}</version>
		</dependency>
	</dependencies>

	<build>
		<pluginManagement>
			<plugins>
				<plugin>
					<groupId>org.apache.maven.plugins</groupId>
					<artifactId>maven-source-plugin</artifactId>
					<version>2.1.1</version>
				</plugin>
			</plugins>
		</pluginManagement>
	</build>

  <modules>
  	<module>commmon-base</module>
  	<module>common-component</module>
  </modules>

在相关业务模块的pom.xml 中添加改组件

<dependency>
			<groupId>com.***</groupId>
			<artifactId>****-common-cron</artifactId>
			<version>${project.version}</version>
		</dependency>

在业务模块中配置文件中application.properties添加改组件初始化参数:

# cron 数据库配置
com.***.ucas.cron.database.url=jdbc:mysql://192.168.1.***:3306/***?serverTimezone=UTC&useSSL=false&allowPublicKeyRetrieval=true
com.***.ucas.cron.database.username=root
com.***.ucas.cron.database.password=***
com.***.ucas.cron.database.driverClassName=com.mysql.cj.jdbc.Driver



声明

1.本站遵循行业规范,任何转载的稿件都会明确标注作者和来源;2.本站的原创文章,请转载时务必注明文章作者和来源,不尊重原创的行为我们将追究责任;3.作者投稿可能会经我们编辑修改或补充。

发表评论
搜索
KIKK导航

KIKK导航

排行榜
关注我们

一个IT知识分享的公众号
